The Rox 01 is a Pininfarina-styled REEV SUV — 5.3 m long, 6 or 7 seats, a 1.5T range extender, 350 kW and 1,115 km of total range.

If you are interested in this model or have any other automotive needs, please feel free to contact us using the form below. With over ten years of experience in the automotive trade, we are here to solve all your problems and provide the best solutions for your requirements.



Category: Tags: ,









The Rox 01 turned up in 2023 wearing the Polestones 01 badge in China, then walked out to the world as ROX. It’s a big, boxy thing that invites comparison to a Defender, yet underneath it runs as a range-extender rather than pure electric — a detail that trips up a lot of first-time lookers. Pininfarina shaped the body, BAW builds it, and the whole pitch is camping and overlanding rather than school-run. On the numbers that matter it’s a 5.3-metre SUV that drives mostly on electricity but never makes you hunt for a charger on a long trip, which is the bit campers genuinely use rather than just read about.

Exterior

Boxy and upright. The LED signature front and rear is a thin inverted-L that reads more like a stamped logo than a light bar, and there’s something honest about a face that doesn’t try to look like every other EV. Size, since everyone asks: 5,295 mm long with the full-size spare bolted to the side-hinged tailgate, 1,980 wide, 1,869 tall, on a 3,010 mm wheelbase — drop the spare and you’re looking at roughly 5.05 m nose to tail, which is the figure that fits most parking signs.

Wheels run 20 or 21 inches, the 21s on 275/45 R21 rubber, and there’s a proper external spare with its own cover — the kind of thing that looks odd in a shopping centre but earns its keep on a trail, and that’s the feature campers genuinely use rather than just read about. Ground clearance sits at 205 mm to the sills, 255 mm under the battery pack, approach 22.2 degrees and departure 25.1, enough to nose into ruts most city SUVs would refuse. Colours keep to the outdoorsy end: grey, white, black and a spruce green that photographs well against rock.

Interior

Calmer in here than the shell outside would have you expect. The six-seat version gets airline-style captain chairs in row two with power leg rests, heating, ventilation and massage; the seven-seat swaps those for a 2+2+3 bench that folds flat into a two-metre bed — and the bit I’d actually point out to a customer is that the bed mode is what sells this car to a family, not the badge. Nappa leather, wood and tungsten-steel trim dress the cabin, and a panoramic roof keeps it bright.

You get three screens across the cabin — a 12.3-inch cluster, a 15.7-inch centre display on a Snapdragon 8155, plus a 15.6-inch panel for the second row — with tri-zone climate, 256-colour ambient lighting and a 14-speaker system rounding it out. The optional tailgate kitchen, hot water and storage and power outlets, is the bit that tells you who this car is really for, and that’s the feature campers genuinely use rather than just read about. Eight airbags and a five-star C-NCAP body sit underneath the comfort, which is the thing parents actually care about.

Powertrain and Chassis

This is where the car differs from a battery-only SUV. A 1.5-litre turbo four sits up front as a generator, not a driveshaft — it makes electricity, the two axles do the turning, and that’s the whole REEV trick. Front and rear motors combine for 350 kW, about 470 hp, and 740 Nm, enough for 0–100 in 5.5 seconds and a 190 km/h ceiling; drive is dual-motor all-wheel, with Snow, Rock, Mud, Sand and Wade modes to sort the torque, which sounds like a brochure list right up until you’re actually stuck in sand.

The pack is a 56 kWh CATL unit, a smaller 44.5 kWh version on the standard-range trims, giving 235 km of WLTC electric range and, with the 70-litre tank filled, 1,115 km total; CLTC runs higher, around 282–306 km electric and 1,338 km combined, and I’d quote the WLTC figure to a customer because it’s the honest one. DC charging peaks at 100 kW — 20 to 80 percent in about 24 minutes — while a 7 kW AC fill takes roughly 8.6 hours, and there’s 2.2 kW of vehicle-to-load per socket for the campsite, which is the bit campers genuinely use rather than just read about. Underneath is an all-aluminium chassis with double wishbones ahead and an H-arm multi-link behind, both with DCC damping and ventilated discs; the body is high-strength steel, not a ladder frame, but the off-road geometry is real — 700 mm wading, a 45-degree climb, 600 mm of axle articulation. Five radars, a dozen ultrasonic sensors and six cameras feed a Level 2 suite, with three LiDAR units optional, which is more eyes than most people will ever need.

FAQ

Is the Rox 01 a pure electric car or a range extender? It’s a REEV — a range-extender. A 1.5T petrol engine generates power but never drives the wheels; the motors do, so you get electric driving day to day. You’ll see 235 km of WLTC electric range, and a 70-litre tank that stretches total range past 1,100 km when the battery runs low. There is no separate pure-BEV version of this model, which catches a few people out next to so many battery-only Chinese SUVs, so it’s worth saying plainly before anyone expects a charging-only life.

How far does it go, and how long does charging take? On WLTC you’ll see 235 km on battery alone and 1,115 km with the range extender working; CLTC quotes closer to 306 km electric and 1,338 km combined, and I’d trust the WLTC number when you’re talking to a customer. Charging the 56 kWh pack from 20 to 80 percent takes about 24 minutes on a 100 kW DC charger, or roughly 8.6 hours on a 7 kW home wallbox. Because it’s a range-extender, a long trip means topping the fuel tank more than the battery, and that changes how you plan stops — honestly a relief for anyone who’s queued at a charger.

Six or seven seats, and can it really go off-road? Both. The six-seat layout uses captain chairs in row two with leg rests and massage; the seven-seat is a 2+2+3 that folds into a flat bed, and the bit I’d actually point out is that the bed is what families remember after a trip. Off-road, the numbers are genuine: 22.2-degree approach, 25.1 departure, 255 mm under the pack, 700 mm wading and a 45-degree climb. It’s not a welded-diff rock crawler, but for overlanding, sand, mud and mountain passes it’s properly capable, and the terrain modes do the fiddly work so you don’t have to.

Can the Rox 01 be imported to my country? Where a market has no import certification requirement, it goes straight in. Some regions do ask for type approval — the EU is the one that comes up most often — so there we confirm first whether this model can be supplied with the certification your destination wants. Send us your country and we’ll check it properly before anything moves.

How do we supply the Rox 01, and how do we start? We’re a China-based auto export trading company, so we source the Rox 01 from the manufacturer and handle the export side — paperwork, booking, sea freight and delivery into your port. Most of the people we work with are overseas dealers and importers building a steady line out of China, though we also help individual buyers running their own import. Tell us your market, drive side and rough volume, and we’ll come back with availability, shipping options and the document list your destination needs.





2023 Polaris 01 All-Purpose 7-Seat Edition2023 Polaris 01 Premium 6-Seat Edition
Basic Information
Availability2023.082023.08
vehicle classMid-size SUVMid-size SUV
Length*Width*Height(mm)5050*1980*18695050*1980*1869
Type of energyadd-on program (Tw)add-on program (Tw)
WLTC pure electric range (km)235235
CLTC pure electric range (km)282282
Combined system power (kW)350350
Combined system torque (N-m)740740
motor1.5T / 152 hp / inline 4-cylinder1.5T / 152 hp / inline 4-cylinder
Maximum power (kW)112112
Number of gears11
transmissionFixed Ratio GearboxFixed Ratio Gearbox
Maximum speed (km/h)190190
0-100km/h acceleration(s)5.55.5
WLTC Combined Fuel Consumption (L/100km)7.957.95
Battery TypeTernary lithium batteryTernary lithium battery
Battery capacity (kWh)56.0156.01
Fast charging time (h)0.480.48
Fast charging capacity (%)0-800-80
Warranty PolicyFive years or 100,000 kilometersFive years or 100,000 kilometers
body of automobile
Length (mm)50505050
Width (mm)19801980
Height (mm)18691869
Wheelbase (mm)30103010
Front wheelbase(mm)16921692
Rear wheelbase(mm)17011701
Weight (kg)26602580
Fuel tank volume (L)7070
Number of doors (pcs)55
Number of seats (pcs)76
motor
Displacement (mL)14961496
Maximum horsepower (Ps)152152
Maximum power (kW)112112
cylinder (engine)Inline 4-cylinderInline 4-cylinder
Intake formturbochargedturbocharged
valve traindouble overhead camshaftdouble overhead camshaft
Lubrication methoddirect injectiondirect injection
Cylinder materialaluminumaluminum
fuel grade95#95#
environmental standardCountry 6Country 6
electric motor
Total motor power (kW)350350
Total motor torque (N-m)740740
Maximum power of front electric motor (kW)150150
Maximum torque of front motor (N-m)340340
Maximum power of rear electric motor (kW)200200
Maximum torque of rear motor (N-m)400400
Combined system power (kW)350350
Combined system torque (N-m)740740
WLTC pure electric range (km)235235
CLTC pure electric range (km)282282
Battery capacity (kWh)56.0156.01
Slow charging time (h)8.68.6
Fast charging time (h)0.480.48
Motor structurepermanent magnetismpermanent magnetism
Principle of motor operationsynchronizationsynchronization
Number of drive motorsDual MotorDual Motor
Motor Layoutfront and rearfront and rear
Battery TypeTernary lithium batteryTernary lithium battery
Battery Cell BrandsNingde TimesNingde Times
Battery cooling methodliquid coolingliquid cooling
fast charging functionbe in favor ofbe in favor of
Fast charging capacity (%)0-800-80
Battery Pack WarrantyEight years or 160,000 kilometersEight years or 160,000 kilometers
external discharge
Chassis/steering
Driving formfour-wheel drivefour-wheel drive
Front suspension typedouble wishbone independent suspensiondouble wishbone independent suspension
Rear suspension typeMulti-link independent suspensionMulti-link independent suspension
Adjustable suspension
Steering assist formelectric power assistelectric power assist
Wheels/Brakes
Front/Rear Brake TypeVentilated tray typeVentilated tray type
Parking brake typeelectronic parkingelectronic parking
Front Tire Specification265/50 R20265/50 R20
Rear Tire Specification265/50 R20265/50 R20
Wheel Materialaluminumaluminum
Spare tire specificationTire Repair ToolsTire Repair Tools
Active/passive safety features
ABS anti-lock
Brake force distribution (EBD/CBC etc.)
Brake Assist (BA/EBA/BAS etc.)
Traction control (ASR/TCS/TRC etc.)
Stability Control (ESC/ESP/DSC etc.)
Active braking/safety systems
merging aid
lane keeping assist system
lane departure warning
Road traffic signage recognition
Fatigue Driving Alertscharacter used in Taiwan as a substitute for a real name (like "X" in English)character used in Taiwan as a substitute for a real name (like "X" in English)
DOW Open Door Alert
front exhaust airbag:: Driver's airbag:: Driver's airbag
●Passenger airbag●Passenger airbag
●Side airbags●Side airbags
●Head airbags (air curtains)●Head airbags (air curtains)
Rear airbags●Head airbags (air curtains)●Head airbags (air curtains)
Tire Pressure Detection Device●Display●Display
Seat Belt Reminder●Principal Driver●Principal Driver
●Passenger●Passenger
ISOFIX child restraints
Forward Collision Warning
Rear Collision Warning
Anti-Rollover System
Auxiliary/Manipulation Configurations
parking radar●Forward●Forward
● Post● Post
Driver Assistance Video●360-degree panoramic image●360-degree panoramic image
Transparent chassis/540 degree imagecharacter used in Taiwan as a substitute for a real name (like "X" in English)character used in Taiwan as a substitute for a real name (like "X" in English)
cruise control●Adaptive cruise at all speeds●Adaptive cruise at all speeds
Driving Mode Switching:: Campaigns:: Campaigns
:: Economy:: Economy
:: Standard/comfort:: Standard/comfort
:: Snow:: Snow
● Off-road● Off-road
steep incline and slow descent
hill-holding aid
automatic parking
automatic parking
remote control
Assisted driving level●L2●L2
External/anti-theft configurations
skylights:: Segmented non-opening sunroof:: Segmented non-opening sunroof
roof rack
Electric Suction Door
Side footrests○Fixed○Fixed
Key Type●Remote key●Remote key
● Bluetooth key● Bluetooth key
Keyless entry
Keyless Start System
Remote start function
Central locking in the car
electronic immobilizer
Internal Configuration
Steering wheel material● Leather● Leather
Steering Wheel Adjustment● Manual● Manual
Adjustable up and downAdjustable up and down
Adjustable front and rearAdjustable front and rear
Steering wheel functions●Heating●Heating
:: Multifunctionality:: Multifunctionality
center armrest●Forward●Forward
● Post● Post
Sun visor vanity mirror
Liquid crystal instrument size12.3 in.12.3 in.
Built-in car recorder
Wireless charging function for cell phones● Front row● Front row
Intelligent Hardware
Assisted Driving Chips○2 NVIDIA Orin-X.○2 NVIDIA Orin-X.
:: Dual TDA4:: Dual TDA4
Number of cameras● 6● 6
○11○11
Number of ultrasonic radars:: 12:: 12
○14○14
Number of millimeter-wave radars● 5● 5
Number of LiDAR○3○3
seating
Seat Material● Leather● Leather
Main Driver's Seat Function:: Memory:: Memory
:: Ventilation:: Ventilation
:: Massage:: Massage
●Heating●Heating
Passenger seat function:: Ventilation:: Ventilation
:: Massage:: Massage
●Heating●Heating
Seat electric adjustment●Principal Driver●Principal Driver
●Passenger●Passenger
Integral adjustment of the main driver's seat●Before and after●Before and after
●Backrests●Backrests
●High/Low (4-way)●High/Low (4-way)
Partial adjustment of the main driver's seat●Leg rests●Leg rests
:: Waist (4-way):: Waist (4-way)
Passenger seat overall adjustment●Before and after●Before and after
●Backrests●Backrests
●High/Low (4-way)●High/Low (4-way)
Partial adjustment of the passenger seat:: Waist (4-way):: Waist (4-way)
Second row seat adjustment●Angle adjustable●Angle adjustable
● Seat movement● Seat movement
●Proportional lowering●Proportional lowering
●Lumbar adjustment●Leg rest adjustment
●Lumbar adjustment
●High and low adjustment
Second row of individual seats
Passenger seat rear adjustable buttons
Rear Cup Holder
Third row of seats
Seat Layout2002/2/32002/2/2
multimedia
Large color screen in the center console
satellite navigation system
Navigating the road information display
Map BrandingBaiduBaidu
Roadside assistance calls
Automotive Intelligence ChipQualcomm Snapdragon 8155Qualcomm Snapdragon 8155
Bluetooth/Car Phone
Cell phone connectivity/mapping●CarPlay support●CarPlay support
●Factory connectivity/mapping●Factory connectivity/mapping
Number of audio speakers1414
Center screen size●15.7 inches●15.7 inches
Voice assistant wake wordsHello, Stone.Hello, Stone.
4G/5G networks●5G●5G
Telematics
OTA upgrade
Car KTV
Rear LCD screen size●15.6 inches●15.6 inches
Interface Support●USB port●USB port
●Type-C port●Type-C port
Power Support●220V/230V power supply●220V/230V power supply
illumination
low beam (headlights)●LED●LED
high beam (headlights)●LED●LED
LED daytime running lights
Adaptive high and low beam
Adjustable headlights
Automatic headlights
Delayed headlight off
Interior ambient lighting
Glass/Mirror
power window●Forward●Forward
● Post● Post
One-touch window lifting● Full vehicle● Full vehicle
Anti Window Pinch Handle
rearview mirror●Motorized adjustment●Motorized adjustment
:: Electric folding:: Electric folding
●Automatic anti-glare●Automatic anti-glare
:: Memory:: Memory
●Heating●Heating
●Automatic folding for locking the car●Automatic folding for locking the car
●Automatic reversing down●Automatic reversing down
rearview mirror●Automatic anti-glare●Automatic anti-glare
●Streaming rearview mirror●Streaming rearview mirror
Glass Functions:: Multi-layer soundproofing:: Multi-layer soundproofing
● Rear side privacy● Rear side privacy
inductive wiper
Air conditioners/refrigerators
Air conditioning control method● Automatic control● Automatic control
Individual air-conditioning in the rear
rear air vent
Temperature zone control
PM2.5 filtration
Negative Ion Generator
