The top of the car is closed, can not be opened; the car is equipped with on-board generator sets, control cabinets, ventilation systems, optional cable tray, etc.; compartments on both sides of the optional different positions and number of exhaust doors, cable doors, maintenance doors, operating doors, air intake doors; compartments around the site lighting (stationary use). Optional tool doors on both sides of the skirt; rear optional lift-up door, reversing camera. Optional door hinge pattern. The lower part of both sides and the lower part of the rear are skirt-type enclosure protection, material Q235, connection method welding, rear protection height from the ground is 460mm. 4KH1CN6LB engine, the net power of 87kW, 4KK1N6LB engine, the net power of 87kW, 4KK1N6SD engine, the net power of 95kW, 4KB1-TCG60 engine, the net power of 9kW. When installing 4KB1-TCG60 engine, the net power is 94kW; with the chassis optional installation of a kind of cab only changing the front panel, front grille, front combination lamps, rearview mirror style, the front signage “4K ENGING/NJR/NHR/NKR/100P”; optional installation of plastic footrest. Different styles and materials of rims (aluminum/iron) are optional; half cab is optional; chrome-plated corner plate, grille and wheel eyebrow are optional with the chassis; different styles of signboards are optional; different styles of front bumper are optional. Only 7.00R16LT 8PR and 7.00R16LT10PR tires are available.
SZY5045XDYQ6 | |
---|---|
Length*Width*Height(mm) | 5995*2120*2200/5995*2050*2200 |
Length (mm) | 5995 |
Width (mm) | 2120/2050 |
Height(mm) | 2200 |
Curb mass (kg) | 4365 |
ABS System | Yes |
Maxium Speed (km/h) | 105/115 |
Number of Seats | 2 |
Front/Rear Overhang (mm) | 1015/620 |
Approach angle (°) | 24 |
Departure angle (°) | 15 |
Chassis ID | 3188454 |
Chassis Model | QL1040BUHAY |
Chassis Category | Category II |
Chassis Name | Truck Chassis |
